PARAMETER

参数

VALUE

NTEP/OIML Accuracy class

精度等级

NTEP III

Non-Approved

C3

Maximum no,of intervals(n)

分度值

5000 single(1)

1000

3000(2)

Y=Ema*Vmin

8000

1400

6000

Standard capacities(Emax)

量程

0.6,1,2,3,6,10,15,20,30,35,60,100,200

Rated Output

额定输出

2.0 mv/v±0.1%

Zero Balance

零点平衡

±3%

Creep after 30 minutes

蠕变

±0.25%

±0.030%

±0.020%

Nonlinearity

非线性

Hysteresis

滞后

±0.25%

±0.030%

±0.020%

Repeatability

重复性

±0.20%

Creep error

蠕变误差

±0.030%

±0.030%

±0.017%

Creep Return

蠕变输出恢复值

±0.030%

±0.030%

±0.017%

Temp.effect on output

灵敏度温漂

±0.0026%

±0.0026%

±0.0014%

Temp.effect on zero

零点温漂

±0.0015%

±0.0015%

±0.008%

Safe Temp.Range

可用温度范围

-10°C to + 40°C

Temp.Compensated

温度补偿范围

-20°C to + 60°C

Safe Overload

安全载荷

150%

Ultimate overload

极限载荷

200%

Input Impedance

输入阻抗

410 ohm±10 ohm

Output Impedance

输出阻抗

350 ohm±3 ohm

Rated Excitation

推荐激励电压

10VDC/AC

Maximum Excitation

最大激励电压

15V DC/AC

Insulation Resistance

绝缘阻抗

>5000 M ohm（50VDC）

Environmental proteciom

防护等级

IP66
